SHAPING SKYLINES WITH PRECISION DETAILING
Total Engineering Consultants delivers fabrication-ready erection plans, assembly sheets, and DSTV CNC data (.NC1) for fabricators and erectors across the USA. We embed AISC design criteria, AWS D1.1 structural welding requirements, and OSHA 1926 Subpart R erection safety clearances directly into our coordinated Tekla models.
AISC & OSHA-COMPLIANT SERVICES
Engineering and detailing services conforming to building code requirements. We deliver files compatible with shop workflows and fabrication machinery.
Structural Engineering & Calculations
AISC 360 and ASCE 7 compliant calculations, foundation design, and PE-stamped engineering documents for steel, concrete, and cold-formed frames.
Structural Steel Detailing
Tekla-modeled erection drawings, assembly details, and shop fabrication sheets. Fully detailed connection plates with CNC files (.NC1) and FabTrol lists.
Miscellaneous Steel Detailing
OSHA 1910.25-29 compliant staircases, handrails, guardrails, access ladders, and platform detailing for industrial and commercial projects.
BIM Modeling & Clash Detection
LOD 400 virtual design and construction models. Comprehensive Navisworks spatial clash detection and MEP/Structural/Architectural coordination.
Rebar Detailing & Placement Drawings
Reinforced concrete detailing matching ACI standards. Complete rebar placement plans, bar bending schedules (BBS), and concrete masonry detailing.
CAD Drafting & Vector Conversions
CAD drafting including high-accuracy raster-to-vector CAD conversion, redline modifications, and DWG standard layouts.
Optimize Shop Throughput & Minimize Fit-Up Rework
Outsourcing structural steel detailing and calculations to Total Engineering Consultants lets you expand your project capacity without adding fixed overhead. We act as an extension of your engineering department, conforming to your shop's specific preferences for bolting, welding, and shipping constraints.
Our in-house QA processes mandate double-check validation of every assembly detail against the structural design drawings, minimizing field fit-up errors.
AISC Code of Standard Practice
All connection detailing, member dimensions, and shop tolerances conform to AISC 303 (Code of Standard Practice) and NISD guidelines.
Tekla & Revit Direct Integration
We deliver coordinate-correct LOD 400 models, DSTV CNC files (.NC1) for saw/drill lines, and DXF files for plate burning.
24-Hour Proposal Turnaround
Submit your structural design package (PDF drawings or 3D models) and receive a firm, itemized engineering proposal within 24 hours.
Strict NDA & Security Protocols
Rigorous data security protocols protect your project IP. Secure file transfers and dedicated server storage for all engineering files.
Serving Major Construction Hubs Nationwide
While we deliver structural design and drafting engineering services to fabricators across all 50 states, we provide localized compliance support in major urban markets.
Houston, TX
Steel detailing services in Houston, TX. AISC shop drawings, erection plans, DSTV CNC files, and Tekla models for Gulf Coast fabricators. Binding quote within 24 hours.
Chicago, IL
Structural engineering services in Chicago, IL. Wind and snow load design, frost-line foundations, steel frame analysis, and permit support. Quote in 24 hours.
New York City, NY
BIM modeling and clash detection in New York City. LOD 400 structural BIM, Navisworks coordination, DOB filing support. 24-hour proposal turnaround.
Los Angeles, CA
Seismic steel detailing in Los Angeles, CA. SMF, BRB, and braced-frame connections per CBC and AISC 341. Tekla shop drawings. Quote within 24 hours.
Atlanta, GA
Pre-engineered metal building design in Atlanta, GA. PEB engineering, steel detailing, anchor plans for warehouses and industrial facilities. Quote in 24 hours.
REQUEST AN ENGINEERING & DETAILING PROPOSAL
Submit your structural contract drawings, design models, or load tables. Receive a comprehensive scope breakdown and binding technical proposal within 24 hours. Conforming to AISC, ACI, and OSHA erection standards.
